Skip to content 1.Fully automatic non-stop unwind & rewind, and the non-stop material changing speed can reach 400m / min
2.The whole machine adopts PC and full servo motor drive control system
3.Full automatic computer automatic color registration and HD color still picture monitoring, which is convenient for the observation of printing quality
4.High precision ceramic anilox roller inking system, fully enclosed ink doctor blade, air pump automatic ink pumping system
5.The central embossing drum with constant temperature control is adopted, and the material is not easy to heat under high-speed operation
6.Closed loop constant tension design of high-precision tension sensor ensures accurate and stable printing tension
7.The high-performance deviation correction system ensures the linear stability of the substrate operation process and the end face uniformity of the winding finished product
8.Independent hot air electric heating and drying unit, high efficiency and energy saving. Heat transfer oil or steam heating mode can also be selected
Main Technical Parameters
| Machine model | PJCI-TS-F-650-1850mm |
| Material width | 600-1800mm |
| Printing width | 570-1770mm |
| Printing color | 4-12color |
| Mechanical speed | 50-500m/min |
| Material diameter | 50-450m/min(Depending on the substrate) |
| Printing length range | 380-860mm |
| Raw material diameter | 800mm |
| Printing precision | ±0.05mm |
| Color registration mode | Automatic registration by computer |
| Machine weight | depends on the model |
| Machine size | depends on the model |
| Working voltage | 3P-380V-50hz |
| Other optional | 1.Turning bar 2. UV device 3. Corona processor device 4. Slitting device |
